Wi-Tek WI-CPE513P-KIT V3: 2x 100Mbps PoE Ports, 5GHz, 5Km, 48V PoE, WiFi AP
Stock Code:
48360
POA
Description
Features:
* Easy to set up* Ultra-bandwidth
* Long-Distance Data Transmission up to 5Km
* PTP/ PTMP
* IEEE 802.3at PoE Power Supply and IEEE 802.3af PoE Out
* Wi-Tek Cloud Management
Hardware Specification:
* Interface: 1x 10/100Mbps WAN (PoE IN) RJ45 port, 1x 10/100Mbps LAN RJ45 port* Frequency Range: 5.150 ~ 5.850GHz (Channel 36~64, 100~144, 149~165)
* Compliant Standards: IEEE 802.11a/n
* Spatial Streams: 2x2, MU-MIMO
* Maximum Wireless Rate: 300Mbps@5GHz
* Antenna Gain Build-in 15dBi directional antenna
* Half Power Beamwidth (Typ.): Horizontal: 30°, Vertical: 30°
* Transmit Power: 24±2dBm max
* Recommended Distance: 5Km
*LED Indicators: System, WAN port, LAN port, 5G
* DIP Switch:
H: Base station mode, supports wireless point-to-point and point-to-multipoint long-distance transmission.
C: CPE mode, a receiving point for connecting a wireless base station.
* Power Supply: IEEE 802.3at PoE IN
* Power Consumption: <9W idle
* Dimensions: 260 x 88 x 56mm
* Weight: 0.40Kg
* Installation: Wall/ Pole mounted
* Material: Outdoor UV Stabilized Plastic
* Ingress Rating: IP65
