Wi-Tek WI-PCES210G-O:8x 100Mbps PoE Ports+ 2x 100Mbps RJ45, 100W O/D Switch IP65
Stock Code:
48255
POA
Description
Wi-Tek's Cloud Easy Smart Outdoor PoE Switches are designed to address the unique challenges of variable weather environments. This Wi-Tek Outdoor PoE Switch, is a cost-effective, all-in-one solution for your outdoor CCTV systems with 8 PoE output ports.IP cameras and other PoE-powered devices can be powered up and transmit data by one Ethernet cable, which shortens the construction period and cost. This series of switches supports Cloud Management to remotely manage your devices in Wi-tek's Cloud Platform/mobile app, providing you with intelligent, simple and easy-to-maintain management measures. Users can view the network status, modify the configuration and troubleshoot from base.
Features:
* Supports 250m Extend mode, Port VLAN mode, PD Alive mode* Supports Wi-Tek Cloud management for real-time monitoring and remote configuration
* Supports alarm notifications, easy to maintain in real-time
* Supports ONVIF protocol to automatically identify IP camera
* IP65 Weatherproof and dustproof enclosure design
Specifications:
* Downlink Ports: 4 x 100Mbps PoE Ports* Uplink Ports: 2 x 100Mbps RJ45 Ports,
* PoE Standard: Port 1-2: Hi-PoE 45W, Port 3-8: 802.3af/at 30W
* PoE Power: 100W Max delivery budget
* Standards & Protocols: IEEE 802.3af, IEEE 802.3at
* Switching Capacity: 5.6 Gbps
* Input Power: 100-240 VAC 50/ 60Hz
* Power Consumption: Idle - 2.4W 100% Traffic Rate with PoE: 102.4W
* Fan Quantity: Fanless
* Certification: CE, FCC, RoHS, UKCA, RCM
* Dimensions: 314 x 210 x 89mm
* Installation: Wall-mount, Pole-mount
* Ingress Rating: IP65
DIP Switch Button:
* 1. Extend: The transmission distance of PoE Port can be up to 250m with 10Mbps
* 2. VLAN: Enable Port isolation, each PoE port just can send data to uplink port
* 3. PD Alive: All PoE ports enable PoE Alive function, which can detect and reboot the offline compliant PoE powered devices
