Utepo UTP5328S-PSD2000: 24x Gigabit PoE 1900W + 4x SFP, L2 Managed
Stock Code:
48740
POA
Warranty Details:
1 Year Return to Base
Description
2 Units only
This switch provides 24 Gigabit downlink RJ-45 Ethernet ports and 4 Gigabit uplink SFP ports. It meets IEEE802.3af/at/bt standard. All downlink RJ-45 Ethernet ports support Power-over-Ethernet (PoE++) and deliver up to 90W per port. Total PoE power budget is up to 1900W. Switch functions can be configured via software. It has extensive L2+ management functions and can be easily managed via a WEB GUI (HTTP/HTTPS), CLI (telnet/ssh/console), or SNMP.
Features:
• 24*10/100/1000Base-T RJ-45 ports• 4*1000Base-X SFP ports
• 1*RJ-45 console port
• 1*OOB port (RJ-45)
• 90W PoE per port
• 1900W PoE for whole switch
• Support Perpetual PoE
• Uninterrupted PoE supply to the powered device during the restart of the switch.
• Support Quick PoE
• When the switch is powered on, it supplies PoE to the powered device in seconds.
• Support PoE watchdog
• CCTV: 1~24 ports are isolated while communication; optimize, flow control to make the video more fluent.
• Online: 24-hour online monitoring device. If a crash fault occurs, it will reboot automatically (PoE watchdog).
• Lock: Lock the authentication port device to prevent illegal access to the equipment and make the system more secure.
• Ring: Start Fast Ring group 1 (Fast Ring group: X1 and X2 uplink ports).
• Redundant power supply
• 6kV surge immunity
• 6kV contact discharge, 8kV air discharge ESD protection
• Metal shell design
• Rack mounted / desktop / wall mounted
