ONETOP MEM2400-LP: Mechanical Mag Lock (Light Panel) Plate Install 800Kg
Stock Code:
58036
POA
Description
The MEM2400-LP is an innovative product which successfully incorporates mechanical designs into the electromagnetic lock. This lock achieves holding forces up to 800Kg and impact resistance up to 200J whilst reducing physical lock size. Plate Install and LSS monitoring for outward opening hinged doors. Tiny footprint, huge holding force, the more you pull on the door the stronger it holds it shut. Gives much more headroom than other conventional magnetic locks with an even stronger holding force. This lock is recommended for outward opening hinged doors <2400mm.
Features:
* Slimline Design: 75% smaller than a standard 800Kg magnet• High holding force up to 680Kg
* Releases under side load of up to 100Kg
• Low power consumption, 24V DC/ 120mA
• Dual-voltage 12V/ 24V DC selectable
• Anti-tamper bracket to protect the armature plates
Specifications:
* Holding Force: Up to 800Kg* Surface Finish: Anodized Aluminium Housing.
- High quality plating for anti-corrosion
* Fail Safe: Power-to-lock
* Impact Resistance: 200J
• Early Warning Alarm (EW) I & II: COM/ NO/ NC Max 0.3A; Max 50VDC
* Lock Status Monitoring (LSS) Output: NO/ NC/ COM, Max 24VDC; Max 2A
* Door Status Monitoring (DSS) Output: NO/ COM, Max 24VDC COM/ NO/ NC Max
* Lock Body: L 158 x H 36 x D 30mm
* Armature Dimension: L 120 x H 30.5 x D 12.5mm
* Weight: 1.7Kg
* Expected Usage Lifespan: Over 1 million cycles
* Standards: CE, RoHS
* Compliance: EN 1634-1:2014, BS EN 1634-1:2014, BS 476-22:1987 (4 Hrs)
* Fire Resistance: Tested to 4 hours, as per AS/NZ 1905.1 – 1997 Part 1 Fire Resistant Doorsets
