Provision-ISR 4CH NVR5 KIT: With 2Tb & 4x 4MP B-Sight Turrets 2.8mm
Stock Code:
33581A
POA
Description
Kit Includes:
1 x Provision-ISR NVR5-4100PXN(MM) 4CH NVR 335044 x Provision-ISR DH-340IPBN-28 B-Sight: 4MP NDAA Turrets Hybrid 33006
1 x WD Purple Hard Drive 3.5" 2Tb Installed - 3 Year Warranty 46073
NVR Features:
* Embedded Cyber Protection: Quantum Iot Nano agent by Check Point™* NDAA: Compliant NVR
* IP Video Inputs: 4
* Onboard PoE: 4 Ports, Max budget, 50W total.
* Bandwidth: Input/ Output, both 64Mbps
* Recording: 4CH @ 5MP real time
* Max Playback: 1CH @ 5MP, 4CH @ D1
* Video Compression: H.265+ / H.265/ H.265S/ H.264
* Display Outputs: 1x HDMI 1920 x 1080, 1x VGA output
* Storage1x HDD bay. 2Tb installed for you.
* Analytic Support: DDA1 & DD2. LPR Capture Only (Eye-Sight). See specification sheet
* Search Mode: DDA Object, Smart Search, LPR, Time-Slice, Time, Event.
* Alarms: IPC. Add Provision-ISR IO-1606 USB Input & Output Module: 33501
* Ethernet Port: 1x 10/100Mbps self-adaptive Ethernet interface
* USB: 2x Ports
* ONVIF Support: Full Device Support (Profiles T/G, ONVIF Version 20.12)
* Power Supply: 48VDC/ 1.04A
* APP Support 1: Provision CAM2 for iOS/ Android
* APP Support 2: IE for Windows 7/8/10, Safari for Mac OS, CMS for Windows/MAC
* Dimensions: W255 x D220 x H45mm
Monitor & UPS Options:
* Provision-ISR 24" Ultra-Thin Monitor: 50008* EATON 5E UPS 700VA/360W, 2x NZ OUTLETS 13071
* EATON 5E UPS 1100VA/660W, 3x NZ OUTLETS 13076
Camera Features:
* 4MP Fixed Lens Dome/Turret Camera* Hybrid LED Illumination: 20m (1 High-Power IR LED) + 20m (1 High-Power White LED)
* Sensor: 1/3" CMOS (16:9)
* Resolution: 2560×1440 25/30FPS (4MP)
* Lens: 2.8mm (93°)
* DRI: Detect - 57m, Recognise - 11m, Identify - 6m
* True Day&Night – ICR
* Compression: H.265+/ H.264+ / H.265 / H.264 / MJPEG
* DDA1 Analytics Human & Vehicle Recogition: Sterile Area, Line Crossing Human only
* Digital WDR, BLC, HLC, ROI
* Built-in Microphone
* ONVIF: Profile S
* Water Proof: IP67
* Weight: ~290g
* Power: DC12V/~350mA / PoE/~4.5W
* Dimensions: 97mm x 97mm x 82.6mm
Accessories:
* IP66 Back Box: PR-JB12IP66 34074* Wall Bracket: PR-WB-A 34078
* Pole Mount: PR-B50PB 34032 and PR-WB12 34083
* Ceiling Mount: PR-CB12 34082 and PR-B10EX extension sections 34062 Guide HERE
