MyNet MX03-LTE-M-LAN 5G Universal Dual SIM, LTE-M Communicator, 2G & LAN, APP
Stock Code:
12840
POA
Description
Multi-network LTE-M communication device. Operates on existing 2G / 4G / NB-IoT networks. Also ready to operate on new LTE-M / 5G networks when the old ones are removed. Provides Up / Downloading via TIP / RING to specific alarm types DSC (PC series), HONEYWELL (Vista), CADDX (NX series), NEO series. Provides increased remote management capabilities of these systems (full & partial arming, disarming, bypass & real status zones) except NEO . It is compatible with all types of central alarm units and has a built-in Global Sim Card. Comes with an application and smartphone app (Android & iPhone) for the end user and the installer.
Stand Alone 'Universal' Communicator - 5G capable
Features:
* Dial Capture Interface: Supports Ademco ContactID, SIA, FF, Pulse 4+2* Dial Capture: Universal DTMF model
* Serial Interface: Wide integration with compatible alarm panels
- Connect to keybus of DSC, Aritech and Honeywell panels
* GSM/GPRS: Quad-band, GPRS Class 12
* Multipath Signalling: GPRS/ SMS
* SIM: Built-in SIM - 5G Connection
* LAN Output: Standard RJ45 LAN connection
* Communication Path: Central monitoring station or Text to Cell Phone
* Installer APP: RControl Admin (Andriod & Apple) - Set up
* End User APP: RControl (Android & Apple) - Arm, disarm, activity log
* Digital Inputs: 2 For key switch zones
* Digital Outputs: 2 Transistor outputs to connect to a PGM, for garage door/ gate control
* Supply Voltage: 12 to 29VDC
* Power Consumption: Nominal 15 mA, Peak 200 mA
* Weight: <75g without Antenna
* Ultra-Compact Dimensions: 63 x 90 x 32mm
* Antenna: Length 10cm, with 90cm extension cable
* Compliance: EN50131, EN50136
Alarm Panel wiring and programming information can be found HERE
Please contact your Sales Representative for associated service fees.
