Wi-Tek WI-PCES226GF: 24x 100Mbps PoE Ports + 2x 1000Mbps Combo, 280W, Cloud
Stock Code:
48065
POA
Description
Wi-Tek's Cloud Easy Smart 250m PoE Switches provide 4/ 8/ 16/ 24 100Mbps PoE ports. Some PoE ports can deliver up to a 90W output, suitable for powering high-power devices and fulfill the demand for sufficient PoE power for HD IP surveillance. It offers an easy-to-use, reliable, intelligent power solution for CCTV networks. This series of switches supports Cloud Management to remotely manage your devices in Wi-Tek's Cloud Management platform/ Mobile App, providing you with intelligent, simple and easy-to-maintain management measures. Users can view the network status, modify configuration and troubleshoot anytime.
Features:
* Cloud Easy Smart 250m PoE switch* Supports Wi-Tek Cloud management, mobile APP remote maintenance
* Smart DIP Mode: Extend mode, VLAN mode, PD Alive mode
* Supports various real-time alarms, even novices can troubleshoot
* Supports ONVIF protocols to automatically identify IP cameras
V1 Specifications:
* Downlink Ports: 24 x 100Mbps PoE Ports* Uplink Ports: 2 x 1000Mbps Combo SFP Ports
* PoE Standard: Port 1-4: 802.3bt 90W, Port 5-24: 802.3af 30W
* PoE Power: 280W Max delivery budget
* Standards & Protocols: IEEE 802.3af/ at, IEEE 802.3bt
* Switching Capacity: 8.8 Gbps
* Input Power: 100-240V AC 50/60Hz
* Power Consumption: Idle - 5.1W 100% Traffic Rate with PoE: 285W
* Fan Quantity: 2
* Certification: CE, FCC, RoHS, UKCA, RCM
* Installation: Rack mount and Wall mount
* Dimensions: 440 x 207 x 44mm
DIP Switch Button:
* 1. Extend: The transmission distance of PoE Port can be up to 250m with 10Mbps
* 2. VLAN: Enable Port isolation, each PoE port can just send data to uplink port
* 3. PD Alive: All PoE ports enable PoE Alive function, which can detect and reboot the offline compliant PoE powered devices
