Provision-ISR 8CH NVR KIT: 4x 6MP S-Sight Turrets 2.8mm 2Tb HDD, 24" Monitor
Stock Code:
33587M
POA
Description
Kit Includes:
4 x Provision-ISR DH-360IPSN-28: S-Sight 6MP NDAA Hybrid Turrets 330271 x Provision-ISR NVR8-4100PN-V2: 4CH 12MP NVR 33556
1 x Hard Drive 3.5" 2Tb Installed 46073
1 x Provision-ISR 24" Monitor 50008
NVR Features:
* Embedded Cyber Protection: Quantum Iot Nano agent by Check Point™* NDAA Compliant NVR
* IP Video Inputs: 8CH RJ45 Direct Connection / Over Network
* Onboard PoE: 8CH, total power 120W
* Max Recording: 8CH x 12MP @ 20FPS, 8CH 8MP @ 25FPS
* Max Input / Output Bandwidth: 80Mbps / 80Mbps
* Max Decoding:1@ 12MP ; 4x 2MP, 8x D1
* Video Compression: H.265/ H.265+ / H.265S / H.264
* Display Outputs: HDMI (4K & 1080P), VGA (1080P, 1280x1024, 1024x768)
* Storage: 1x SATA HDD bay. 2Tb installed for you.
* PTZ support: Via Network
* Ethernet Uplink Port: 1000 Mbps (RJ-45)
* Analytic Support: DDA2, Face Recognition, LPR & Fish-Eyes (camera dependent)
* Audio: 1 Channel IN, 1 Channel OUT
* Alarm Input/ Output: 8 + IPC
* Dimensions: W300 x D250 x H50mm
* APP Support 1: Provision CAM2 for iOS/ Android.
* APP Support 2: IE for Windows 7/8/10, Safari for Mac OS, CMS for Windows/MAC
UPS Options:
* EATON 5E UPS 700VA/360W, 2x NZ OUTLETS 13071* EATON 5E UPS 1100VA/660W, 3x NZ OUTLETS 13076
Camera Features:
* Quantum IoT Nano agent by Check Point™* NDAA: Compliant Camera
* Sensor: 1/2.5" CMOS (16:9)
* Resolution: 3200×1800 20FPS (6MP)
* Lens: 2.8mm 103° (H)
* Day & Night: ICR + 24/7 Full-Colour Day Mode
* Image Enhancement: True WDR (120dB), BLC, HLC, ROI
* Illumination: 20m (1 High-Power IR LED) 20m (1 High-Power White LED)
* Compression: H.265+/ H.264+ / H.265 / H.264 / MJPEG
* Aanlytics (Human & Vehicle Object Recognition): DDA1 Sterile Area, Line Crossing
* SD Card: Event/ Schedule Record (Up to 256GB) 46039
* Audio: Built-in Microphone + Audio input
* ONVIF: Profiles M/ T/ S/ G
* Ingress Rating: Water Proof, IP67. Full metal case.
* Power: DC12V/~400mA / PoE/~7.5W
* Dimensions: Ø97× 82.6mm
Accessories:
* IP66 Back Box: PR-JB12IP66 34074* Wall Bracket: PR-WB-A 34078
* Pole Mount: PR-B50PB 34032 and PR-WB12 34083
* Ceiling Mount: PR-CB12 34082 and PR-B10EX extension sections 34062
